^^^^ those are Work Gnosis GS1



the natural negative camber you get by lowering is enough for those to fit flush



That setup will fit flush with a decent drop (i.e. Eibachs) and less than -2.00* of camber in the rear.
You'd be looking at about -1.80* give or take in order to have them fit flush and not have any rubbing issues.
Just correct the toe and you won't have any tire wear issues, just a bit of camber wear.



^ Based on my set-up, this sounds just about right to me.

I'm currently running the following set-up on my V36 Sedan with absolutely no rubbing:
Front: 20" x 9.5" +25 with 245/35R20 (-1.7° camber)
Rear: 20" x 10.5" +37 with 285/30R20 (-2.5° camber)



Thanks guys for the help. I could very well be placing an order for some new wheels real soon.



How low are you? Cuz I was rubbing the crap out in the front on my plastic liner with +35 offset and -2.0 camber. hahaha

Man... I really need to fix those wheels and put some tires on.



I forgot to ask, is your camber spec with you inside the car??



^1
Wow, I wanna know too. I have 245/35/20 on 9.5" +25 fronts and I rub very slightly on the fender liner bracket on bumps and that's with -2.24*.
I'm dropping down to 235/35's when tirerack gets my rear 255/35's in stock to fix that issue (and match the rear stretch).

And I agree Alan, get the wheels fixed and put them on ASAP.



I usually have the car set so there's about one finger gap between the tire and the fender, but I've also dropped it down so the tire is even with the fender and still no rubbing. Where exactly are you rubbing the plastic fender liner, Alan? There is a bump in the upper front section of the plastic that may rub, but once it wears down (or if you grind it down) then there's not much else to rub..

Nope, that's the camber specs on an alignment rack without me in the car. Those specs are with the car set with a "one finger" gap. When I drop it down lower the front camber is around -1.9°, but still no rubbing.

I did have to trip the rear felt fender liner when I went from 275's to 285's in the rear, but haven't rubber since.



mrr gt1
20x8.5 +38 245/35/20
20x10 +43 285/30/20
dropped on eibach pro kit
For those with X's who hesitate to run staggered, do it!



19x9 F. Fronts need Spacers. im rockin 15mm on the front
19x10 +30 Rears.
I love how they look on red. Aheem. hehe



Been a while since I posted pics of my car. Have since added the front lip and BC CO's.



Looks great, man! Love the wheels!



nice!



Konig Afterburner 20x8.5" front, 40mm offset, 20x10" rears, 40mm offset
235/30/20 tires front, stretched 245/35/20 rears
